2 in Diamond Core Bit

A 2 in diamond core bit with 5 teeth and a 15 3/4 in overall length. A common job for this size: sprinkler branch line through a block wall.

Call 718-344-1474 or request a quote. Delivery to all five NYC boroughs.

2 in Diamond Core Bit Rental in Brooklyn, NYC

The 2 in diamond core bit cuts a round hole about 2 in across through concrete, block, brick and stone on a core drill. It has 5 diamond teeth and a 15 3/4 in overall length. Rent it from our Brooklyn yard at 181 2nd Ave, or have it delivered with your drill anywhere in the five boroughs. Call 718-344-1474.

2 in core bit for a sprinkler branch line through a block wall

A Manhattan office fit-out extends the sprinkler system into a new row of offices, and a 1 1/4 in branch line has to cross a concrete block corridor wall. 1 1/4 in steel sprinkler pipe is 1.660 in on the outside. A 2 in core leaves about 5/32 in each side, inside the gap range many firestop sealants allow for small steel pipe through a rated wall.

Tip: Check the firestop system your contractor is using before you pick the bit. Each listed system has a minimum and maximum gap, and the bit size is how you hit it.

Is 2 in the right size?

Measure the outside of the pipe, duct or sleeve that has to fit, not the size printed on it. Then leave room for sealant, grout or firestop around it. In the job above, that works out to about 5/32 in each side.

Specifications and Features

Bit size2 in
Overall length15 3/4 in
Number of teeth5
TypeDiamond core bit

Rental Details

Equipment typeCore Drill
Rental periodsDaily, weekly, monthly
Pickup181 2nd Ave, Brooklyn, NY 11215
DeliveryAll five NYC boroughs
RatesCall 718-344-1474
AvailabilityCall or request a quote
Ready to rent the 2 in Diamond Core Bit?Call 718-344-1474 or request a quote

Which drill: this size runs on the EDCO handheld core drill for walls and tight spots, or on a 36 in core drill rig for floors. Already have a drill? Tell us the model when you request a quote and we will check that the bit fits it.

Drill wet. Keep water running to cool the bit and keep silica dust down, and read the OSHA guidance on crystalline silica before you start. Scan slabs for rebar, conduit and post-tension cables before you core a floor.

2 in Diamond Core Bit delivery in NYC

We deliver from our yard at 181 2nd Ave, Brooklyn, to job sites in all five boroughs. Call 718-344-1474 or request a quote.
